S/N

Features

1

Basic Requirement

JCHUB-Cast is used for wireless transmission between JCTOUCH & Portable Device to interactive with each other.

JCHUB-Share is Click & Share, our JCHUB is already build in JCHUB-Cast Module, so no need JCHUB-Cast, can use JCHUB-Share directly.

JCHUB-Cast & JCHUB-Share is very stable, drop line rate＜1time/3hour，Multi-screen distance＞25m

1、System Version: Android 5.1；

2、Central Processor: ARM Cortex A17 x 4；

3、Ram: 2G DDR3 ；

4、SoftAP 802.11ac 5.8G AP， Wifi & SoftAP；

5、WiFi frequency：5.8G/2.4G Dual Frequency；

6、Support Windows 7/8/10,iosIOS 9.0 and Above ,Apple Mac system；Mac OSX 10.6/10.7/10.8/10.9

7、Support AirPlay or Mirror cast

2

Ports

1、HDMI Output, 1280*720P/1920*1080P；

2、Lan portRJ45*1,USB*2，wifi antenna*2；

3、Front panel have power , data and wifi indicator

3

Audio

1、Support H.264,H.265,VP8,RV,WMV,AVS,H.263,MPEG4,Video decoding，Video Frame Rate 18-30 rate；

2、Video decoding resolution: 1920*1080P；

3、Input Resolution: 1024×768-1280×720-1920×1080

4

JCHUB-Share

1、WIFI：5.8G AP or 5.8G STA

2、Port: USB Device

3、Support Windows 7/8/10, Apple Mac

4、Resolution：720P~1080P，Frame Rate：Video/Audio 18~30rate

5、Lag: 100~200ms

6、Multi-screen Display

7、10 touch points feedback（Windows 7/8/10）

8、Support Mouse feedback（Windows xp,Mac）

9、 1~8 channels

10、Wireless rate emitter 300Mbps

11、Wireless transmission protocol IEEE 802.11 a/g/n/ac

12、Band：5.8G， WPA2-PSK

5

PC Network Mirror Cast

1、Configuration：Same local network

2、Support：Windows 7/8/10,Apple Mac

3、Resolution：720P~1080P，Rate：Video/Audio 18~30

4、Lag：100~200ms

5、Touch Feedback：Support Mouse feedback（Windows,Mac）

6、Network connection：Recommend RJ45或5G WIFI（Our JCHUB Have 5G WIFI AP）

6

Environment

Power Input: DC：220V,10W

Environment Temperature ：Working Temperature 0℃~40℃，Working Humidity10%~90%

7

Accessories

1*Power Cable，1*HDMI cable，2*WIFI Cable
